5430-929 Woodward overspeed protector

Price:

Product basic information
Manufacturer: Woodward
Model: 5430-929
Belonging to the famous 505 series
Supports multiple communication protocols and can be smoothly integrated with the existing control system of the factory
Core application: Designed specifically for speed control and protection of steam turbines
5430-929 controller has stable performance and high reliability

Categories: WOODWARD
Tags: - Actuator 5430-929 controller debugger module Motor touch screen WOODWARD

5430-929 Woodward overspeed protector

The 5430-929 is a microprocessor-based digital governor controller produced by Woodward, belonging to its classic 505 series.
It is primarily designed for speed control and protection of steam turbines. Below is a detailed introduction to this product:

I. Product Overview

Brand and Model: Woodward 5430-929
Series: 505 Series Digital Governor
Type: Microprocessor-based controller
Purpose: Specifically designed for steam turbines to control their speed and provide overspeed protection.

II. Core Functions

Speed Control:
- 5430-929 Precisely controls the speed of steam turbines by adjusting steam inlet flow.
- Supports single-range or split-range actuators to accommodate turbines of different sizes.
Overspeed Protection:
- Incorporates triple independent overspeed protection logic to ensure rapid shutdown in case of overspeed, preventing equipment damage.
- Provides an overspeed test button for convenient on-site testing of protection functions.
Emergency Shutdown:
- Equipped with an emergency stop button for immediate shutdown in emergency situations.
System Protection:
- - Automatically switches control modes upon sensor failure to ensure uninterrupted system operation.
  - Offers local/remote control priority selection to adapt to different operational scenarios.

What does PWM controller mean
March 23, 2010 13:35 www.elecfans.com Author: Anonymous User Comment (0)
Keywords: Controller (168368) PWM (208388) PWM Controller (35392)What does PWM controller mean

The Basic Principles and Application Examples of Pulse Width Modulation

Pulse width modulation (PWM) is a highly effective technique for controlling analog circuits using the digital output of microprocessors. It is widely used in many fields, from measurement and communication to power control and conversion.

analog circuit
The value of an analog signal can vary continuously, with no limitations on its time and amplitude resolution. A 9V battery is an analog device because its output voltage is not exactly equal to 9V, but varies over time and can take any real value. Similarly,

the current absorbed from the battery is not limited to a set of possible values. The difference between analog signals and digital signals is that the values of the latter can usually only belong to a predetermined set of possible values,

such as in the set of {0V, 5V}. Analog voltage and current can be directly used for control, such as controlling the volume of a car radio. In a simple analog radio, the volume knob is connected to a variable resistor. When turning the knob,

the resistance value increases or decreases; The current flowing through this resistor also increases or decreases, thereby changing the current value that drives the speaker, causing the volume to increase or decrease accordingly. Like a radio, the output of an analog circuit is linearly proportional to the input.

III. Technical Specifications

Power Supply: 18-32 VDC, supporting 24VDC input.
Display: Two-line x 24-character LED display for clear indication of operating status and parameters.
Enclosure: NEMA 4X or IEC 60529 IP56 rated for protection against harsh industrial environments.
Inputs/Outputs:
- Inputs: 6 programmable current inputs, 16 discrete contact inputs.
- Outputs: 2 actuator outputs, 8 relay outputs, 6 programmable current outputs.
Communication Interfaces: 5430-929 Supports RS-232, RS-422, and RS-485 hardware interfaces for easy integration with host computers or other devices.
Software: Equipped with OpView™ and 505View software for parameter configuration, monitoring, and fault diagnosis.
Operating Temperature: -20 to +60°C (some models support -4 to +140°F).
Storage Temperature: -40 to +85°C (some models support -40 to +185°F).
5430-929 Weight: Approximately 9.11 pounds (4.13 kilograms).

IV. Application Scenarios

Steam Turbine Control: 5430-929Suitable for steam turbines of various sizes, including industrial steam turbines, small grid turbo-generators, and turboexpanders.
Single Extraction and Admission Applications: Designed for operating steam turbines in single extraction and/or admission applications.
On-Site Programming: Allows on-site operators to program and adjust parameters through an integrated operator control panel, adapting to different operating conditions.

V. Product Advantages

High Reliability:
- Microprocessor-based design ensures precise control and stability.
- Triple independent overspeed protection logic provides multiple layers of safety.
Flexibility:
- 5430-929 Supports various actuator and sensor configurations to accommodate different turbine models.
- Offers a rich set of input/output interfaces for easy system expansion and integration.
Ease of Use:
- Two-line x 24-character LED display provides an intuitive operating interface.
- A 30-key multifunctional keyboard simplifies parameter configuration and operation.
Compatibility:
- Supports multiple communication protocols for easy integration with DCS, PLC, and other systems.
- Provides OpView™ and 505View software for remote monitoring and fault diagnosis.
